BTS320-14/19/26/36/50 LED Dual Color Profile Spotlight
Optical parameters:
Light source: single COB LED dual color temperature module
Color temperature: 2800K-6200K color temperature linearly adjustable
Average lifespan: 50000 hours
Color rendering index: Ra≥95
Light flux: 22200lm
Spot angle:14°/19°/26°/36°/50° Optional
Lens: Aspheric lens
Electrical parameters:
Input voltage: AC100-240V,50/60Hz
Rated power: 320W Power factor PF≥0.98
Drive current: 1.45A
Control System:
Dimming: 0-100% linear dimming, stroboscopic effect 0-20 times/sec
Control protocol: standard DMX512 protocol RDM function
Channel mode: 2CH/4CH/5CH
Heat dissipation system: It adopts a high thermal conductivity copper tube radiator, and the intelligent monitoring technology of the silent fan automatically adjusts the rotation speed according to the temperature of the lamp.
Noise: 1 meter noise ≤ 35db
Control Interface:DMX512 interface three-core/five-core, Daisy-chain Power
Appearance specifications:
Size:
724×304×513mm（BTS320-14)
660×370×447mm
Weight: 10Kg
Color: Black
Shell: Aluminum die-casting
Protection: IP20
Working environment: -30℃~45℃
Accessories: Power cord/Signal line/Insurance rope/Light hook
Temperature monitoring: built-in temperature sensor, automatically adjust the power for over-temperature protection, real-time view on the display panel.
